A small ionization chamber detector has been developed for monitoring the intensity of hard X-ray beam for Synchrotron facilities around the world. The small dimensions of the ionization chamber (20 mm along the beam direction and 30 mm perpendicular to it) make it possible to place it very close to the sample.​​

Window Aperture - 10 mm Diameter ​​

2-D Drawing

Ion Chambers​

IC-400-100

  • Window Aperture: 20mm x 35mm
  • Dimensions (w/o base): 113.8(W) x 254.3(L) x 113.8(H) mm
  • Electrode Length: 200mm
2-D Drawing
  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base): 113.8(W) x 154.3(L) x 113.8(H) mm
  • Electrode Length: 100mm
2-D Drawing
2-D Drawing
2-D Drawing
  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base): 96.75(W) x 104.3(L) x 66(H) mm
  • ​Electrode Length: 50mm
  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base): 96.75(W) x 254.3(L) x 66(H) mm
  • Electrode Length: 200mm

IC-400-200

2-D Drawing
2-D Drawing

IC-400 Series

Operating potential up to 1.7 kV

​​IC-500-50

IC-400-50

​​IC-500-200

This compact detector is designed for alignment and direct measurement of X-ray beams. The detector system consists of a photodiode and miniature coaxial connector to interface with an electronics package. Three different photodiode sizes are available: 20mm x 20mm, 10mm x 10mm, and 5mm x 5mm.

Micro Ion Chamber

​MIC-205

​​IC-500-100

  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base): 113.8(W) x 208.6(L) x 113.8(H) mm
  • Electrode Length: 50mm

IC-500 Series

Operating potential up to 1.7 kV

​ADC's ion chambers are designed for precise, low noise x-ray measurement. The electrodes are constructed of nickel plated copper on fiberglass supports, all housed within a nickel plated aluminum frame. Each electrode is connected to an SHV connector. ¼" push to connect style fittings comprise the gas connections. The system can be configured for air, vacuum, or ultra high vacuum operation through one of three interfaces.

As with all ADC products customization is available.

607-5333531

2-D Drawing
  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base): 96.75(W) x 154.3(L) x 66(H) mm
  • Electrode Length: 100mm
  • Window Aperture: 25mm x 40mm
  • Dimensions (w/o base):113.8(W) x 104.3(L) x 113.8(H) mm
  • ​​Electrode Length: 50mm

X-Ray Beam Monitor

IC-400-50-XY
